Honeywell RA116A1055 protectorelay® oil burner control


Protectorelay Oil Burner Control with 75 seconds lock out timing. RA116A 1055
One-piece, stack-mounted oil burner primary controls that cycle the burner on and shut down the burner on flame loss or system malfunction.
Combine a Protectorelay unit for cycling the burner and a Pyrostat flame detector for sensing temperature changes of flue gases up to 1000 F (556 C).
Manual reset of safety switch required after ignition failure completely shuts off main burner.
Include manual trip safety switch to assure burner shutdown during servicing.
Mount with flange for mounting on curved or flat surfaces.
Use with line voltage or 24 Vac Control Circuit.
Protectorelay Oil Burner Control with 75 seconds lock out timing
Mount with flange for mounting on curved or flat surfaces.
6 in. high x 5 3/16 in. wide x 3 3/16 in. deep
152 mm high x 132 mm wide x 81 mm deep
UL Listed; File no.MP268, Guide no. MCCZ
CSA Certified; File no. LR95329-1
